Ball valve

Ball Valves product page:

Ball Valves are used to either shut-off or open flow passage and their easy operation provides unrestricted flow. Due to their volumetric structure they work rapidly and efficiently, and prevent cavitation. Ball Valves can be locked in the open or closed position through a locking washer on the circle pin. The internal ball has a hard chrome coated steel, and delrin (POM) seat. Ball Valves are suitable for LPG, CNG and other gas applications, as well as hydraulic and other industrial fluids.

Material

Body Material                                 Carbon steel
Ball Material                                   Hard chrome coated carbon steel.
Thread Size                                     BSP, NPT
Ball Seats                                        Delrin (POM)
Sealing                                            Nitrile O-ring (NBR)
Working Temperature                -30 °C and +110 °C
Plating                                            Zinc Plating (Cr III Passivation)

Upon Request                              VITON
